GA-M68M-S2P

SCHEDA MADRE GIGABYTE GA-M68M-S2P (rev. 1.0) All in One per AMD SK-AM2+/AM3

La scheda madre GA-M68M-S2P dispone del chipset NVIDIA nForce 630A con socket AM2+ e supporto ai processori AMD Phenom II / Phenom / Athlon anche serie AM3. Supporto alle memorie ddr2 fino a 1066 Mhz, grafica integrata NVIDIA GeForce 7025 con supporto CineFX 3.0 per immagini brillanti, fluide e realistiche. Supporto a Sata II 3Gb / s con 4 porte integrate, 8 porte USB 2.0

Processore Support for Socket AM3 / AM2+ / AM2 processors: AMD PhenomT II / AMD PhenomT / AMD AthlonT II / AMD AthlonT / AMD SempronT
Chipset NVIDIA® GeForce 7025 / nForce 630a
iTE IT8718
RTL 8201CL chip (10/100 Mbit)
Realtek ALC888B codec
Memoria 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB
Support for DDR2 1066*/800/667 MHz memory modules
Consultare la lista delle memorie supportate per maggiori informazioni.
Connettori Interni I/O 1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
1 x CD in
1 x Chassis Intrusion connector
1 x CPU fan connector
1 x floppy disk drive connector
1 x front audio connector
1 x front panel connector
1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
1 x power LED connector
1 x SPDIF in/out
1 x Surround/Center connector
1 x system fan connector
2 x USB 2.0/1.1 connectors for additional 4 ports by cables
4x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
Slot di Espansione 1 x PCI Express x1
1 x PCI Express x16
2 x PCI
Pannello Posteriore I/O 1 x COM
1 x D-Sub
1 x LPT
1 x RJ45 LAN
